1.8mm-2.5mm Field Wire Fence Easy Assembled For Orchard / Garden
Hinged Knot Fence
Horizontal wires: 10
Height in inch: 46-inches
Fence length in feet: 330 feet
Mesh hole space: 12 inch
Filling wire: 14.5gauge
Top and bottom wire: 11 gauge
Zinc coating thickness 9g/m2: 60
Ibs / roll: 92-Ibs
47" Field Fence Hinged Joint Knot
47 inch Fence in 330 feet roll length
Horizontal Wires 10
Filler Wire 14 gauge
Top/Bottom Wire 12.5 gauge
Stay wires spacing: 6 inch
Galvanizing: Class III Galvanized (245g/m2)
For USA
4' Height Farm and Ranch Fence for Goats
Rolls of net fence, in 330 ft. rolls, 4 feet tall
Sheep fencing for USA
Farm and ranch fence to keep sheep / goats
Hinged Joint Field Fence
Woven from high tensile 12½ gauge wire. Rolls are 330' long. These
rolls feature strong, flexible hinged-joint construction which
enables the fence to conform to uneven terrain. Crimped horizontal
wires allow for expansion and contraction. All rolls are 20 rods in
length. Vertical wires are one continuous piece with a third piece
of wire connecting them to the horizontal wires.
Hinged Joint Field Fence Uses:
Livestock fencing and confinement.
Erosion control silt fence backing.
Perimeter and boundary fence.
Hinged Joint Field Fence Features
Class 3 zinc coated.
High tensile wire.
Meets or exceeds ASTM A-116.
Hinged Joint Field Fence Advantages:
Fast and easy to install.
Resistant under severe weather conditions.
High tensile wire will not stretch and sag like low tensile wire.
Technical Parameters of Field Fence
● Material: Hot-dip galvanised wire, zinc-aluminium alloy wire
● Top and bottom wire diameter: 2.0mm - 3.7mm
● Intermediate horizontal wire diameter:1.6mm - 3.0mm
● Vertical wire diameter: 1.6mm - 3.0mm
● Field Fence Height: 90cm - 200cm
Table 1: Different Wire Diameters of Hinge Joint Fence | Light duty fence | Middle duty fence | Heavy duty fence | Extra heavy duty fence |
|---|
| Wire Diameter (mm) | Minimum Tensile Strength (N/Mm2) | Wire Diameter (mm) | Minimum Tensile Strength (N/mm2) | Wire Diameter (mm) | Minimum Tensile Strength (N/mm2) | Wire Diameter (mm) | Minimum Tensile Strength (N/mm2) |
|---|
| Top and bottom wire | 2.0 | 650 | 2.5 | 650 | 3.0 | 650 | 3.7 | 650 |
|---|
| Line wires | 1.6 | 450 | 2.0 | 450 | 2.5 | 400 | 3.0 | 400 |
|---|
Table 2: Popular Specifications of Hinge Joint Fence| Hinge Joint Field Fence Types | Fence Height (mm) | Horizontal Wires Number | Distance Between The Vertical Wires (mm) | Mesh Opening Number – Mesh Height (mm) | Roll Length (m) |
|---|
| EZHJF1050/13/15 | 1050 | 13 | 150 | 6–75, 6–100 | 50, 100, 150 |
|---|
| EZHJF1250/15/15 | 1250 | 15 | 150 | 6–75, 8–100 |
|---|
| EZHJF1550/18/15 | 1550 | 18 | 150 | 6–75, 11–100 |
|---|
| EZHJF1550/15/15 | 1550 | 15 | 150 | 11–100, 3–150 |
|---|
| EZHJF1850/20/15 | 1850 | 20 | 150 | 6–75, 11–100, 2–150 |
|---|
| EZHJF1850/16/15 | 1850 | 16 | 150 | 10–100, 3–150, 2–200 |
|---|
| EZHJF1950/17/15 | 1950 | 17 | 150 | 11–100, 3–150, 2–200 |
|---|
| EZHJF2000/21/15 | 2000 | 21 | 150 | 6–75, 11–100, 3–150 |
|---|
| EZHJF2400/23/15 | 2400 | 23 | 150 | 6–75, 11–100, 3–150, 2–200 |
|---|
Field Fence Types
Hinge Joint (Monarch Knot)
Hinge Joint Field Fencing with hinged joints are formed by winding
vertical wires around horizontal wires. This construction can
withstand a lot of pressure and can spring back to its original
shape quickly after an impact. Each joint is made by winding the
two vertical wires individually around the horizontal wires,
resulting in greater strength and flexibility.
FAQ
1. Who are we?
We are based in Hebei, China, start from 2009, selling to Southeast
Asia(15.00%),Oceania(15.00%),South America(12.00%),Eastern
Europe(10.00%),Domestic Market(10.00%),Mid
East(8.00%),Africa(6.00%),Western Europe(6.00%),North
America(5.00%),Eastern Asia(3.00%),Central America(3.00%),Northern
Europe(3.00%),Southern Europe(2.00%),South Asia(2.00%).
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.What can you buy from us?
All kinds of wire mesh and related products, such as wire mesh
fence, barbed wire, razor wire, gabion box, chain link fence, steel
grating, temporary fence, expanded metal sheet, stainless steel
wire mesh, window screen and so on.
4. Why should you buy from us not from other suppliers?
We are specialized in fence and wire mesh field since 2009. We can
supply the most suitable and best solutions. Qualified products and
professional service is our main purpose.
5. What services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF, EXW, FCA, DDP, DDU;
Accepted Payment Currency: USD, EUR, CNY;
Accepted Payment Type: T/T, L/C, D/P, D/A, Credit Card, Western
Union, Cash, Escrow;
Language Spoken: English, Chinese, Japanese, Korean, France
