    Press Locked Steel Grating , Serrated Surface Bar Grating Manufacturers

    Ask Lasest Price
    Brand Name : Giant Shuttle
    Model Number : WW-00011
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : L/C, T/T,
    Supply Ability : 5000 Square Meters/Week
    Delivery Time : 7Days after receive the deposit
    • Product Details
    • Company Profile

    Press Locked Steel Grating , Serrated Surface Bar Grating Manufacturers

    Press Locked Steel Grating , Serrated Surface Bar Grating Manufacturers


    Press-locked steel grating also can be called pressure locked grating, it is made of low carbon steel or stainless steel. With the performance of high bearing capacity, non-slip, anti-corrosion and easy to install and remove, pressure locked grating is widely used for ceilings, platforms, floors, fence and all kinds of cover in the factories, civil and commercial buildings.

    Two press-locked steel grating with different mesh sizes which people often use: 33 mm × 33 mm, 33 mm × 11 mm.


    Classification of serrations:
    Materials: low carbon steel and stainless steel.
    Surface treatment: galvanized, painted or powder coated.
    Surface type: smooth surface and serrated surface
    Serrated surface type:
    1: Trapezoidal teeth on the bearing bar.
    2: Trapezoidal tooth both on the bearing bar and cross bar with the highest non-slip performance. In this three types. it is most popular.
    3: The non-slip tooth is applied to the connect components. It has the lowest non-slip performance.


    Types of press-locked steel grating by insertion angles and insertion modes.

    According to the different insertion angles and insertion modes, it can be divided into four types: common type, integral type, heavy duty steel grating and louver steel grating.


    Features of Press Locked Steel Grating


    High strength and load capacity.
    Anti-slip surface.
    Corrosion resistance.
    Good drainage function.
    Easy to install and maintain.


    Applications of Press Locked Steel Grating


    Platform services in industrial and energy construction.
    Walkway of bridges and transitions.
    Shelf of factory and supermarket.
    Ceiling of factory, house and hall.
    Gully and well cover of street and huge yard.
    Fence of balcony, factory and playground.
    Floor of many places.


    Specifications of Press Locked Steel Grating

    TypePlain / Smooth, Serrated /teeth, I bar, serrated-I bar
    Load /Bearing bar size20×3,25×3,25×5,30×3,30×4,30×5,32×3,32×5……120×10mm,etc.
    Load /Bearing bar pitch12.5,15,20,25,30,35,40,50mm
    Transverse /Cross bar pitch38,50,80,100mm
    MaterialLow carbon steel, stainless steel, aluminum alloy
    Surface treatmentUntreated, hot galvanized, painting,electro galvanized

    Grating Standard

    China: YB/T 4001.1-2007

    USA: ANSI/NAAMM(MBG531-88)

    UK: BS 4592-1987

    Australia: AS 1657-1985


    Material standard

    China: GB 700-88

    UK: BS 4360:1990

    USA: ASTM A36/A36M-96

    AUSTRALIA: AS 3679


    HDG standard

    CHINA: GB/T13912-2002

    UK: BS729

    USA: ASTM A123/A123M-97a

    AUSTRALIA: AS 1650
